In order to avoid the seasonal change of the transmission oil RAVENOL Getriebeoel EPX SAE 85W-90 GL 5 5 was developed. It can be used in winter as well as in summer.
RAVENOL Getriebeoel EPX SAE 85W-90 GL5 guarantees due to the balanced additive combination characteristics like a high pressure absorption capacity, a superior viscosity temperature behaviour, a high oxidation stability, low pour points, a good corrosion protection and non-sludging.
Application Note
RAVENOL Getriebeoel EPX SAE 85W-90 GL 5 is compatible with all brand-name transmission oils. No “flushing” required when switching to RAVENOL Getriebeoel EPX SAE 85W-90 GL 5.
Use RAVENOL Getriebeoel EPX SAE 85W-90 GL 5 in hypoid gears for hypoid gearbox, manual transmissions, axle drives, distributor and intermediate transmissions in vehicles and working machines.
Characteristics
- Optimal cold flow property
- Outstanding wear protection even with short trips in winter
- High pressure stable lubrication film, thus outstanding wear protection under any stress
- Reduced transmission noise and the best transmission efficiency under full load, i.e. even with very hot oil.
- Outstanding shearing stability
- Excellent oxidation stability, no foaming
- No oil thickening or deposits
- Extraordinary ageing stability
- Excellent viscosity-temperature properties
- Effective wear protection
- Extraordinary corrosion protection, no rust, won’t harm non-ferrous metals
- Neutral to sealants, transmissions stay tight, no oil loss
Мүнөздөмөлөр
| Параметр | Маани | Аудит |
|---|---|---|
| Туурасы, mm | 580 | |
| Узундугу, mm | 580 | |
| Бийиктиги, mm | 885 | |
| Brand | RAVENOL | |
| Илешкектүүлүк | 85W-90 | |
| Тығыздык 20°Cде, g/cm³ | 882 | EN ISO 12185 |
| Илешкектүүлүк 100°Cде, mm²/s | 14.3 | DIN 51562-1 |
| Илешкектүүлүк 40°Cде, mm²/s | 130.3 | DIN 51562-1 |
| Илешкектүүлүк индекси VI | 108 | DIN ISO 2909 |
| Brookfield боюнча илешкектүүлүк 26°Cде, mPa*s | 60.100 | ASTM D2983 |
| Муздоо температурасы, °C | -33 | DIN ISO 3016 |
| Жануу температурасы, °C | 222 | DIN EN ISO 2592 |
| Медине коррозия тести, 121°C / 3 саат | 1b | ASTM D130 |
| Ford | 1781297 |
| Ford | 5000166 |
| Ford | 5000167 |
| Ford | 5009922 |
| Ford | A72SX19K261CA |
| Ford | A72SX19K261DA |
| Ford | A82SX19K261AA |
| Toyota | 0888500500 |
| Toyota | 0888500503 |
